MIPI 13MP OV13850 Camera Module Cmos Digital Image Sensor Types

Name: MIPI 13MP OV13850 Camera Module Cmos Digital Image Sensor Types
Brand: SINCERE FIRST
Price: 1 USD

China MIPI 13MP OV13850 Camera Module Cmos Digital Image Sensor Types factory

Brand Name : SINCERE FIRST

Model Number : SF-V3850M7A21 REAR V1.3

Certification : CE, FCC, RoHS, REACH, ISO

Place of Origin : Guangdong , China

MOQ : 5 pcs

Price : Negotiable

Payment Terms : L/C, Western Union, T/T, MoneyGram, Paypal and Others

Supply Ability : 350000 pcs / month

Delivery Time : 7 - 15 Work Days

Packaging Details : Package, Carton Box

Image Sensor : OV13850

Connector : MOLEX:503776-2410

Focusing Range : 20cm to infinity

Focal Length : 2.33mm

F Number : 2.4

Fov(H) : 125°

TV Distortion : <-25%

Resolution : 13MP

Interface : MIPI

Type : CMOS

Contact Now

Low Cost 13MP OV13850 Cmos Digital Image Camera Sensor Types

Specificaitons

Base Product Number	‎LI-OV13850
Supplier Device Package	Module
Pixel Size	2µm x 2µm
Interface	Serial
Type	CMOS
Lens Mount	M12
Frames per Second	100
Resolution	4416 x 1242
Color	RGB
Product Status	Active

Description

OV13850 is a 13-megapixel camera sensor produced by OmniVision Technologies. It is a high-performance PureCel™ 13-megapixel CameraChip™ sensor that delivers best-in-class high- and low-light performance, as well as dramatically reduced power consumption for smartphones and tablets. It has a 1/3.06-inch optical format and a pixel size of 1.12 microns.

Features

◆1.12 um x 1.12 um pixel with OmniBSI-3M technology
◆optical size of 1/3.06"
◆31.2°CRA for <6mm z-height
◆programmable controls for frame rate, mirror and flip,
cropping,and windowing
◆support for image sizes:13.2MP(4224x3136)
10MP(16:9-4224x2376)4K2K(3840x2160)
EIS 1080p(2112x1188),EIS 720p(1408x792),and
more
◆13.2MP at 30 fps
◆two-wire serial bus control(SCCB)
◆strobe output to control flash

◆8kbits of embedded one-time programmable(OTP)
memory
◆two on-chip phase lock loops(PLLs)
◆frame exposure mode for still image (with mechanical shutter)
◆programmable controls: gain,exposure,frame rate image size, horizontal mirror, vertical flip,cropping, and panning
◆image quality controls: defect pixel correction, automatic black level calibration,lens shading correction,and alternate row HDR
◆built-in temperature sensor
◆suitable for module size of 8.5 mm x 8.5 mm x < 6mm

Applicaitons

PC Multimedia
Tablets

Smart Medical

MIPI 13MP OV13850 Camera Module Cmos Digital Image Sensor Types
